Mech-Mind is a leading company focusing on industrial 3D cameras and AI-powered software, dedicated to advancing intelligent robotics technology. By combining 3D vision with AI technology, the Mech-Mind team continuously innovates globally, setting new standards for robotics technology and elevating automation to a higher level. Our intelligent robots possess exceptional agility and reliability, capable of 'seeing, thinking, and acting', empowering industries to tackle the most challenging automation tasks, including box picking, pallet unloading, part picking, assembly, and quality inspection.
DS Technology has joined as an authorized distributor of Mech-Mind, collaborating to promote its advanced 3D vision and AI automation solutions. We are not only responsible for product sales but also offer complete capabilities in application development, system integration, maintenance services, and technical support. We assist customers in integrating intelligent vision technology to enhance automation production efficiency and precision. Through Mech-Mind’s leading AI 3D vision technology, combined with DS Technology’s professional expertise and industry experience, we are committed to driving innovative developments in robotics applications and providing smarter and more efficient automation solutions to our customers.
| 3D Camera |  |  |  |  |  |  |  |  |  |  |
|---|---|---|---|---|---|---|---|---|---|---|
| Model | UHP-140-GL | PRO XS-GL | NANO-GL | NANO ULTRA-GL | PRO S-GL | PRO M-GL | LSR S-GL | LSR L-GL | LSR XL-GL | DEEP-GL |
| *Working distance (mm) | 300 ± 20 | 300–600 | 300–600 | 250–800 | 500–1000 | 1000–2000 | 500–1500 | 1200–3000 | 1600–3500 | 1200–3500 |
| Near FOV (mm) | 135 × 90 @ 0.28 m | 220 × 160 @ 0.3 m | 220 × 150 @ 0.3 m | 220 × 165 @ 0.25 m | 370 × 240 @ 0.5 m | 800 × 450 @ 1.0 m | 480 × 360 @ 0.5 m | 1200 × 1000 @ 1.2 m | 1280 × 1280 @ 1.6 m | 1200 × 1000 @ 1.2 m |
| Far FOV (mm) | 150 × 100 @ 0.32 m | 430 × 320 @ 0.6 m | 440 × 300 @ 0.6 m | 770 × 550 @ 0.8 m | 800 × 450 @ 1.0 m | 1500 × 890 @ 2.0 m | 1500 × 1200 @ 1.5 m | 3000 × 2400 @ 3.0 m | 3000 × 2800 @ 3.5 m | 3500 × 2800 @ 3.5 m |
| Resolution | 2048 × 1536 | 1280 × 1024 | 1280 × 1024 | 2400 × 1800 | 1920 × 1200 | 1920 × 1200 | Depth Map: 2048 × 1536 RGB: 4000 × 3000, 2000 × 1500 | Depth Map: 2048 × 1536 RGB: 4000 × 3000, 2000 × 1500 | Depth Map: 2448 × 2040 RGB: 4000 × 3000, 2000 × 1500 | Depth Map: 2048 × 1536 RGB: 2000 × 1500 |
| Megapixels | 3 MP | 1.3 MP | 1.3 MP | 4.3 MP | 2.3 MP | 2.3 MP | / | / | / | / |
| **Point Z-value repeatability (σ) | 2.6 μm @ 0.3 m | 0.1 mm @ 0.5 m | 0.1 mm @ 0.5 m | 0.1 mm @ 0.6 m | 0.05 mm @ 1 m | 0.2 mm @ 2 m | 0.2 mm @ 1.5 m | 0.5 mm @ 3 m | 0.2 mm @ 3 m | 1.0 mm @ 3 m |
| ***Measurement accuracy (VDI/VDE) | 0.03 mm @ 0.3 m | 0.1 mm @ 0.5 m | 0.1 mm @ 0.5 m | 0.1 mm @ 0.6 m | 0.1 mm @ 1 m | 0.2 mm @ 2 m | 1.0 mm @ 1.5 m | 1.0 mm @ 3 m | 1.0 mm @ 3 m | 3.0 mm @ 3 m |
| Typical capture time (s) | 0.6–0.9 | 0.7–1.1 | 0.6–1.1 | 0.5–0.9 | 0.3–0.6 | 0.3–0.6 | 0.5–0.9 | 0.5–0.9 | 0.6–1.1 | 0.5–0.9 |
| Baseline (mm) | 80 | 93 | 68 | 86 | 180 | 270 | 140 | 380 | 800 | 300 |
| Dimensions (mm) | 260 × 65 × 142 | 160 × 52 × 87 | 145 × 51 × 85 | 125 × 46 × 76 | 265 × 57 × 100 | 353 × 57 × 100 | 228 × 77 × 126 | 459 × 77 × 86 | 942 × 88 × 116 | 366 × 77 × 92 |
| Weight (kg) | 1.9 | 0.8 | 0.7 | 0.7 | 1.6 | 1.9 | 1.9 | 2.9 | 4.5 | 2.4 |
| Operating temperature (℃) | 0-45 | -10–45 | ||||||||
| Communication interface | Gigabit Ethernet | Gigabit Ethernet | ||||||||
| Image sensor | Sony CMOS for high-end machine vision | High-performance CMOS for high-end machine vision | Sony CMOS for high-end machinevision | |||||||
| Input | 24V DC, 3.75 A | 24V DC, 1.5 A | 24V DC, 3.75 A | 24V DC, 3.75 A | ||||||
| Safety and EMC | CE/FCC/VCCI/KC/ISED/NRTL | |||||||||
| Light source | Blue LED (459 nm, RG2) | Blue LED (459 nm, RG2)/White LED(RG2) | Blue LED (440 nm, RG2) | Blue LED (459 nm, RG2)/White LED(RG2) | Red laser (638 nm, Class 2) | |||||
| IP rating | IP65 | IP67 | IP65 | |||||||
| Cooling | Passive | Passive | ||||||||
| Remark | * Various object focal distances are available for a single camera model. For details, please refer to the technical specifications. ** The standard deviation of the single point Z value for 100 measurements. The measurement target is a ceramic plate. *** Standard: VDI/VDE2634 Part II. For information on discontinued models, please refer to camera materials of previous models. | |||||||||
